2019 Caterpillar 239D Compact Track Loader – CAT0239DCHC900629
Request more information:
2019 Caterpillar 239D3 Compact Track Loader – OROPs, ISO Controls, Manual Coupler, 74″ Smooth Bucket.
| BRAND |
Caterpillar |
|---|---|
| MODEL |
239D |
| CONDITION |
Used |
| YEAR |
2019 |
| HOURS |
1,236 |
| HORSEPOWER |
67 hp |
| ROPS |
Open |
| OPERATING WEIGHT |
7,289 lbs |
| PRODUCT |
Track Loader |
| LOCATION |
Fenton, MO |
Luby Equipment is the authorized CASE CE & Takeuchi dealer of St. Louis, MO and the surrounding areas that has been in business for 50 years. We have the knowledge and experience to give you peace of mind when purchasing new and used equipment. Always Transparent, Globally Trusted. Call us today!
2021 Caterpillar 239D Compact Track Loader for Sale
OROPs, ISO Controls, Manual Coupler, 74″ Smooth Bucket.
The 2019 Caterpillar 239D3 is a compact track loader with a 67.1 hp engine, a 1,530 lb rated operating capacity at 35% tipping load, and an approximate operating weight of 7,434 lb.
Engine & Performance
The 239D3 is equipped with a Cat C2.2 CRDI turbo diesel engine that meets Tier 4 Final and Stage V emission standards.
- Gross Power: 67.1 hp (50.1 kW)
- Net Power: 65.8 hp (49.1 kW)
- Peak Torque: 153 lb-ft (208 N·m) at 1,500 rpm
- Displacement: 134.3 in³ (2.2 L)
- Travel Speed: 5 mph (one-speed) or 7.6 mph (two-speed)
Operating Specifications
The loader features a radial lift design, which provides good mid-lift reach and digging performance.
- Rated Operating Capacity (35% Tipping Load): 1,530 lb (695 kg)
- Rated Operating Capacity with Optional Counterweight: 2,400 lb (1,090 kg)
- Tipping Load: 4,370 lb (1,985 kg)
- Breakout Force (Tilt Cylinder): 3,913 lb (1,775 kg)
- Operating Weight: 7,434 lb (3,372 kg)
- Ground Pressure (with 320 mm/12.6 in tracks): 5.4 psi (37.3 kPa)
Dimensions & Capacities
The 239D3 is designed to be compact, allowing it to navigate tight spaces.
- Overall Height (to top of cab): 80.1 in (2034 mm)
- Overall Length (with bucket on ground): 127.3 in (3234 mm)
- Vehicle Width (with 320 mm/12.6 in tracks): 66 in (1676 mm)
- Ground Clearance: 7.7 in (195 mm)
- Fuel Capacity: 15.1 gal (57 L)
- Hydraulic System Capacity: 11.9 gal (45 L)
Hydraulic System
The hydraulic system is adaptable with options for standard or high flow, suiting various job requirements.
- Standard Flow: 18 gpm (69 L/min)
- High Flow (Optional): 26 gpm (99 L/min)
- System Pressure: 3,336 psi (23 000 kPa)
Additional information
| Condition | Used |
|---|---|
| Hours | 1,236 |
| Year | 2019 |
| Location | Fenton, MO |
