2023 CASE CX42D Mini (Compact) Excavator – EQ0038456
$56,595.00
Request more information:
2023 CASE CX42D Mini Excavator, available for sale at Luby Equipment – Cab, HVAC, 24″ Tooth, 36″ Ditching Bucket.
| BRAND |
CASE |
|---|---|
| MODEL |
CX42D |
| CONDITION |
Used |
| YEAR |
2023 |
| HOURS |
524 |
| HORSEPOWER |
43.2 hp |
| ROPS |
Enclosed |
| OPERATING WEIGHT |
9,259 lbs |
| PRODUCT |
Mini Excavator |
| LOCATION |
Springfield, MO |
PDF Brochure: CASE CX42D Mini Excavator Brochure
PDF Specifications: CASE CX42D Mini Excavator Specifications
2023 CASE CX42D Mini (Compact) Excavator for Sale
Cab, HVAC, 24″ Tooth, 36″ Ditching Bucket.
The CASE CX42D Mini Excavator, available for sale at Luby Equipment, is a 4.2-metric-ton machine that sets the benchmark with its zero tail-swing design for unparalleled proximity to tasks. Standardized with top-tier features and enhanced by performance-boosting options, it promises automotive-like cab comfort, prioritizing the operator’s experience. Equipped with standard auxiliary hydraulics, the CX42D is a versatile attachment platform, elevating service capabilities and driving project profitability.
Engine
- Model: Kubota D1803-CR-T / D1803
- Gross Power (SAE J1995 @ 2300 RPM): 43.3 hp (32.3 kW)
- Displacement: 1,826 cc (111.4 in³)
- Cylinders: 3
- Cooling: Liquid-cooled
- Fuel Type: Diesel
- Emissions: Tier 4 Final
Operating Weight
- Canopy, Short Arm: 9,259 lb (4,200 kg)
- Canopy, Long Arm w/ counterweight: 9,921 lb (4,500 kg)
- Cab, Short Arm: 9,590 lb (4,350 kg)
- Cab, Long Arm w/ counterweight: 10,251 lb (4,650 kg)
Hydraulics / Auxiliary
- AUX 1 – Max Flow: 18.5 gpm (70 L/min) @ 2,900 psi (200 bar)
- AUX 2 – Max Flow: 10.6 gpm (40 L/min) @ 4,061 psi (280 bar)
- AUX 3 – Max Flow: 10.6 gpm (40 L/min) @ 4,061 psi (280 bar)
- Load Sensing closed center hydraulics w/ “Flow Sharing” control valve
Travel / Drive
- Travel Speeds (2-speed w/ auto-shift):
- 1st: 1.6 mph (2.6 kph)
- 2nd: 2.8 mph (4.5 kph)
- Ground Pressure: ~4.1–4.3 psi (0.29–0.3 kgf/cm²)
- Maximum Traction Force: 9,577 lbf (42.6 kN)
Dimensions & Performance
- Boom Swing Angle: 71° left / 56° right
- Swing Speed: 10.5 RPM
- Long Arm (optional): 5 ft-5 in (1.65 m)
- Standard Arm: 4 ft-7 in (1.4 m)
- Digging Depth (from EU data): ~3085 mm (~10 ft 1 in) (approximation based on EU info)
Capacities
- Fuel Tank: 15.9 gal (60 L)
- Hydraulic Tank Refill: 13.2 gal (50 L)
- Total Hydraulic System: 17.2 gal (65 L)
- Engine Oil: 1.8 gal (7 L)
- Cooling System: 2.4 gal (9 L)
Electrical
- Voltage: 12 Volts
- Alternator: 70 amp
- Battery: 12 V x 74 Ah
Sound & Comfort
- Internal Sound Level (ISO6396): Cab ~74 dBA / Canopy ~81 dBA
- External Sound Power: 96 dBA
- Vibrations (ISO 2631): Hand 0.98 m/s² / Whole body 0.45 m/s²
Counterweights & Options
- Standard Counterweight: 110 lb (50 kg)
- Additional: 617 lb (280 kg)
- Heavy Additional: 925 lb (420 kg)
- Optional steel tracks, rear view camera, rotating beacon, LED lighting packages, and more
Additional information
| Condition | Used |
|---|---|
| Location | Springfield, MO |
