The Hitachi Wheel Loader ZW140-7 is engineered for high-efficiency loading, stockpiling, and construction applications that demand consistent daily production. Positioned above compact and entry-level mid-size loaders, the ZW140-7 delivers increased lifting capacity, strong breakout force, and smooth hydraulic response for demanding job site conditions.
Advanced hydraulic tuning provides responsive bucket control for precise loading and grading tasks, while intelligent engine management helps optimize fuel efficiency without compromising power. Its balanced chassis design supports stable lifting performance during truck loading and material placement.
Built for durability and sustained output, the ZW140-7 offers dependable operation across construction, municipal, and aggregate environments. It delivers the stability, strength, and long-term reliability expected from a production-class Hitachi wheel loader.
ZX17U-5n Specifications
Specifications
Bucket capacity (m³) ISO Heaped:
2.5 – 3.1 yd³ (1.9 – 2.4 m³)
Net Rated Power:
154 HP (115 kW)
Operating Weight:
25,760 – 26,490 lb. (11,680 – 12,010 kg)
Breakout force (kN):
21,300 lbf (94.8 kN)
Engine
Model
CUMMINS B4.5
Type
4 cycle water-cooled, direct injection
Aspiration
Turbocharger and intercooled
Aftertreatment
DPF+SCR system
No. of cylinders
4
Maximum power
ECE R120 gross
154 HP (115 kW) at 2,200 min-¹
ISO 9249 : 2007 net
153 HP (114 kW) at 2,200 min-¹
Rated power
ISO 14396 : 2002
154 HP (115 kW) at 2,200 min-¹
ISO 9249 : 2007 net
153 HP (114 kW) at 2,200 min-¹
Maximum Torque
ISO 9249 : 2007 net
519 lbf ft (704 Nm) at 1,200 min-¹
Bore and stroke
4.2″ x 4.9″ (107 mm x 124 mm)
Piston displacement
273.4 in3 (4.46 L)
Batteries
2 x 12 V
Air cleaner
Two element dry type with restriction indicator
Power Train
Transmission
Electronically controlled 2 motor hydrostatic transmission with summation gear box, Gear box : Fixed gear ratio, powershift countershaft type
Cooling method
Forced Circulation Type
Travel speed* Forward/Reverse
Operating Mode
Standard Mode
Power Mode
1st mph (km/h)
8.1 (13) / 8.1 (13)
8.1 (13) / 8.1 (13)
2nd mph (km/h)
8.1 (13) / 8.1 (13)
8.1 (13) / 8.1 (13)
3rd mph (km/h)
12.4 (20) / 12.4 (20)
12.4 (20) / 12.4 (20)
4th mph (km/h)
24.2 (39) / 24.2 (39)
24.2 (39) / 24.2 (39)
*With 16.9-24-10 (L2) tires
Axle and Final Drive
Drive system
Four-wheel drive system
Front and rear axle
Semi-floating
Front
Fixed to the front frame
Rear
Trunnion support
Reduction and differential gear
Two-stage reduction with torque proportional differential
