The Hitachi Wheel Loader ZW180-7 is engineered for high-production loading, aggregate handling, and demanding construction environments. Positioned above the ZW160-7 in capacity and output, the ZW180-7 delivers increased breakout force, strong lifting performance, and fast cycle times to support heavy daily workloads.
Designed with advanced hydraulic tuning and intelligent engine management, this mid-size production wheel loader balances power and fuel efficiency to help control operating costs while maintaining consistent performance. Its optimized linkage geometry and balanced chassis design support stable lifting and confident material placement under load.
Built for long-term durability in quarry, infrastructure, and site development applications, the ZW180-7 provides dependable performance, responsive controls, and operator comfort designed for extended shifts. Engineered to meet the demands of modern production environments, it delivers the strength and reliability expected from Hitachi Construction Equipment.
ZX17U-5n Specifications
Specifications
Bucket capacity (m³) ISO Heaped:
3.4 – 4.2 yd³ (2.6 – 3.2 m³)
Net Rated Power:
168 HP (125 kW)
Operating Weight:
33,245 – 33,797 lb (15,080 – 15,330 kg)
Breakout force (kN):
25,650 lbf (114 kN)
Engine
Model
CUMMINS B6.7
Type
4 cycle water-cooled, direct injection
Aspiration
Turbocharger and intercooled
Aftertreatment
DPF+SCR system
No. of cylinders
6
Maximum power
ECE R120 gross
173 HP (129 kW) at 2 200 min-¹ (rpm)
ISO 9249 : 2007 net
168 HP (125 kW) at 2 200 min-¹ (rpm)
Rated power
ISO 14396 : 2002
173 HP (129 kW) at 2 200 min-¹ (rpm)
ISO 9249 : 2007 net
168 HP (125 kW) at 2 200 min-¹ (rpm)
Maximum Torque
ISO 9249 : 2007 net
815 ft lbf (1 104 Nm) at 1 100 min-¹ (rpm)
gross
827 ft lbf (1 120 Nm) at 1 100 min-¹ (rpm)
Bore and stroke
4.2″ x 4.9″ (107 mm X 124 mm)
Piston displacement
410.1 cu.in (6.69 L)
Batteries
2 x 12 V
Air cleaner
Two element dry type with restriction indicator
Power Train
Transmission
Torque converter, countershaft type powershift with computer-controlled automatic shift and manual shift features included.
Torque converter
Three elements, single stage, single phase
Main clutch
Wet hydraulic, multi-disc type
Cooling method
Forced circulation type
Travel speed* Forward/Reverse
Operating Mode
Standard Mode
Power Mode
1st mph (km/h)
3.7 (5.9) / 3.9 (6.2)
3.9 (6.3) / 4.1 (6.6)
2nd mph (km/h)
7.1 (11.5) / 7.5 (12.1)
7.6 (12.2) / 8.0 (12.9)
3rd mph (km/h)
10.9 (17.5) / 16.5 (26.5
11.5 (18.5) / 17.6 (28.3)
4th mph (km/h)
15.7 (25.3)
16.8 (27)
5th mph (km/h)
24.2 (39)
24.2 (39)
*With 20.5 R25 (L3) tires
Axle and Final Drive
Drive system
Four-wheel drive system
Front and rear axle
Semi-floating
Front
Fixed to the front frame
Rear
Trunnion support
Reduction and differential gear
Two stage reduction with limited slip differential
Oscillation angle
Total 20° (+10°, -10°)
Final drives
Heavy-duty planetary, mounted inboard
Tires
Tire size
20.5R25 (L3)
Brakes
Service brakes
Inboard mounted fully hydraulic 4 wheel wet disc brakes. Front and rear independent brake circuit
Parking brakes
Spring applied, hydraulically released, dry disc type with external output shaft
Steering System
Type
Articulated frame steering
Steering angle
Each direction 40°; total 80°
Cylinders
Double-acting piston type
No. x Bore x Stroke
2 x 2.8″ x 17.4″ ( 2 x 70 mm x 442 mm)
Hydraulic System
Arm and bucket are controlled by multifunction lever
Arm controls
Four position valve; Raise, hold, lower, float
Bucket controls with automatic bucket return-to-dig control
Three position valve; Roll back, hold, dump
Main pump (Serve as steering pump)
Variable Displacement Axial Plunger Pump
Maximum flow
59.1 gal (224 L) /min at 2 200 min-¹ (rpm)
Maximum pressure
3,974 psi (27.4 MPa)
Fan pump
Fixed Displacement Gear Pump
Maximum flow
14.5 gal (54.8 L) /min at 2,200 min-¹ (rpm)
Maximum pressure
2,640 psi (18.2 MPa)
Hydraulic cylinders
ZW160-7
Type
Double acting type
No. x Bore x Stroke
Arm: 2 x 4.9″ x 30″ (2 x 125 mm x 760 mm) Bucket: 1 x 5.9″ x 19.5″ (1 x 150 mm x 495 mm)
Filters
Full-flow 10 micron return filter in reservoir
ZW160PL-7
Type
Double acting type
No. x Bore x Stroke
Arm: 2 x 4.9″ x 30.1″ (2 x 125 mm x 765 mm) Bucket: 1 x 5.9″ x 19.5″ (1 x 150 mm x 495 mm)
Filters
Full-flow 15 micron return filter in reservoir
Hydraulic cycle times
ZW180-7
Lift arm raise
5.3 s
Lift arm lower
3.7 s
Bucket dump
1.1 s
Total
10.1 s
ZW160PL-7
Lift arm raise
5.3 s
Lift arm lower
3.7 s
Bucket dump
2.3 s
Total
11.3 s
*Data at power mode
Environment
Engine Emissions
EPA Final Tier 4 / EU stage V
Sound Level
Sound level in cabin according to ISO 6396: 2008
67 LpA dB(A)
External sound level according To ISO 6395: 2008 and EU Directive 2000/14/EC
