The Hitachi Wheel Loader ZW220-7 is built for high-production loading, aggregate handling, and demanding construction applications. Designed to move large volumes of material efficiently, the ZW220-7 delivers strong breakout force, fast cycle times, and stable lifting performance across heavy daily workloads.
Advanced hydraulic control and intelligent engine management systems work together to provide responsive bucket operation while improving fuel efficiency. The balanced frame and loader arm geometry support confident truck loading, stockpiling, and material placement in quarry and infrastructure environments.
Engineered for durability under sustained production conditions, the ZW220-7 combines power, stability, and long-term reliability. Built to meet the expectations of contractors and fleet owners, it delivers the performance and efficiency expected from Hitachi Construction Equipment in mid-size production wheel loader applications.
ZX17U-5n Specifications
Specifications
Bucket capacity (m³) ISO Heaped:
3.7 – 4.7 yd³ (2.8 – 3.6 m³)
Net Rated Power:
204 HP (152 kW)
Operating Weight:
40,013 – 41,094 lb (18,150 – 18,640 kg)
Breakout force (kN):
32,625 lbf (145 kN)
Engine
Model
CUMMINS B6.7
Type
4 cycle water-cooled, direct injection
Aspiration
Turbocharger and intercooled
Aftertreatment
DPF+SCR system
No. of cylinders
6
Maximum power
ECE R120 gross
157 kW (210 hp) at 1 900 min-¹
ISO 9249 : 2007 net
152 kW (204 hp) at 1 900 min-¹
Rated power
ISO 14396 : 2002
149 kW (200 hp) at 2 200 min-¹
ISO 9249 : 2007 net
144 kW (193 hp) at 2 200 min-¹
Maximum Torque
ISO 9249 : 2007 net
714 ft lbf (967 Nm) at 1 300 min-¹ (rpm)
gross
731 ft lbf (990 Nm) at 1 300 min-¹ (rpm)
Bore and stroke
4.2″ x 4.9″ (107 mm x 124 mm)
Piston displacement
410.1 cu.in (6.69 L)
Batteries
2 x 12 V
Air cleaner
Two element dry type with restriction indicator
Power Train
Transmission
Torque convertershaft type powershift with computer-controlled automatic shift and manual shift features included.
