Hitachi Excavator ZX160LC-7H
The Hitachi Excavator ZX160LC-7H is engineered for high-production excavation and demanding job site conditions. Built on a long carriage platform for enhanced stability, the ZX160LC-7H delivers strong breakout force, smooth hydraulic control, and consistent performance across large-scale earthmoving, utility, and infrastructure projects.
As part of the advanced ZAXIS-7 lineup, this excavator integrates refined hydraulic tuning, improved fuel efficiency, and modern operator technology to maximize productivity and reduce operating costs. The balanced chassis design supports confident lifting and precise multi-function operation, even in challenging environments.
Designed for durability and long-term reliability, the ZX160LC-7H provides the power and control contractors expect from Hitachi Construction Equipment .
Long Carriage Stability
Extended undercarriage design enhances balance and lifting performance for demanding excavation tasks.
ZAXIS-7 Next Generation Systems
Advanced machine technology improves fuel efficiency, productivity, and overall operating value.
High-Performance Hydraulics
Refined hydraulic response delivers smooth multi-function operation and strong digging force.
Fuel-Efficient Engine Management
Optimized engine performance supports reduced operating costs without sacrificing power.
Modern Operator Interface
Advanced in-cab display provides access to machine data, work modes, and performance settings.
Simplified Maintenance
Grouped service points and durable components help minimize downtime and streamline routine inspections.
Specifications Net Rated Power 132 HP (98.6 kW) Operating Weight 39,683 lb (18,000 kg) Max. Digging Reach at Ground Level 30 ft 1 in (9.16 m) Max. Digging Depth 21 ft 4 in (6.49 m)
Working Ranges Arm Length 10′ 1″ (3.08 m)
Model Yanmar 4TN107 Type 4-cycle water-cooled, common rail direct injection Aspiration Turbocharged, intercooled, cooled EGR Aftertreatment DOC + CSF + SCR system No. of cylinders 4 Rated power ISO 14396: Gross 136 HP (101.3 kW) at 1 900 min ISO 9249: Net 132 HP (98.6 kW) at 1 900 min Maximum Torque 444 lbf (602 Nm) at 1 500 min Piston displacement 278.697 cu.in. (4.567 L) Bore and Stroke 4.2″ x 5.0″ (107 mm x 127 mm) Batteries 2 x 12 V / 93 Ah
Hydraulic Pumps Main pumps 2 variable displacement axial piston pumps Maximum Oil flow 2 x 50 gal/min (190 L/min) Pilot Pump 1 gear pump Maximum Oil Flow 8.4 gal/min (31.9 L/min)
Hydraulic Motors Travel 2 variable displacement axial piston motors Swing 1 axial piston motor
Relief Valve Settings Implement circuit 4,974.8 psi (34.3 MPa) Swing circuit 4,249.6 psi (29.3 MPa) Travel circuit 4,974.8 psi (34.3 MPa) Pilot circuit 565.6 psi (3.9 MPa) Power boost 5,511.4 psi (38.0 MPa)
Hydraulic Cylinders | ZX75US-7
Quantity Bore Rod Diameter Boom 2 4.3″ (110 mm) 3.2″ (80 mm) Arm 1 4.7″ (120 mm) 3.5″ (90 mm) Bucket 1 4.1″ (105 mm) 3.0″ (75 mm)
Revolving Frame D-Section frame for resistance to deformation Swing Device Axial piston motor with planetary reduction gear is bathed in oil. Swing parking brake is spring-set/hydraulic released disc type Swing speed 13.3 min Swing torque 32 453 lbf (44.0 kNm)
Tracks Heat-treated connecting pins with dirt seals. Hydraulic (grease) track adjusters with shock-absorbing recoil springs.
Numbers of Rollers and Shoes on Each Side Upper rollers 2 Lower rollers 7 Track Shoes 43 Track Guards 1
Travel Device Each track driven by a 2-speed axial piston motor Parking brake is spring-set/hydraulic-released disc type. Travel Speeds High : 0 to 3.3 mph (0 to 5.3 km/h) Maximum traction force 36,869 lbf (164 kN) Gradeability 70% (35 degrees) continuous
Service Refill Capacities
Fuel tank 75.2 gal (285.0 L) Engine coolant 6.1 gal (23.0 L) Engine oil 5.8 gal (22.0 L) Swing device 1.8 gal (6.9 L) Travel device (each side) 1.8 gal (6.8 L) Hydraulic system 55.4 gal (210.0 L) Hydraulic oil tank 33.0 gal (125.0 L) DEF/AdBlue® tank 9.2 gal (35.0 L)
Weights and Ground Pressure
Operating Weight and Ground Pressure
Shoe Type Shoe width Arm Length, ft-in(m) ZX160LC-7H Monoblock lb (kg) psi (kPa) Triple gouser 24″ (600) 8′ 6″ (2.58 m) 39,463 (17,900) 34,300 (15,600) Triple gouser 28″ (700) 8′ 6″ (2.58 m) 39,904 (18,100) 34,800 (15,800)
Including 0.68 yd³ (0.52 m³) (ISO 7451: 2007 heaped) bucket weight (1,102 Ib (500 kg)) and counterweight (6,724 Ib (3,050 kg))
Bucket and ARM Digging Force
ZX160LC-7H ZX160LC-7H Arm length 8′ 6″ (2.58 m) 10′ 1″ (3.08 m) Bucket digging force ISO 6015 : 2006 25,179 (112) 25,179 (112) Arm crowd force ISO 6015 : 2006 20,458 (91) 18,209 (81)
